- CPU: 1xEight Core E5-2680 2.7Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
Tag: Máy chủ Dell , Máy chủ HP , Máy chủ IBM , Linh kiện server , Nguồn server HP , Nguồn Server IBM , Nguồn Server Dell , Card Raid Server , Card mạng server , Mainboard Server , Máy tính bộ Dell , Thiết bị mạng , Switch Cisco , Router Cisco , Firewall Cisco , Thiết bị lưu trữ , Bộ lưu điện , Tủ Rack - Tủ mạng , Cho thuê máy chủ ,Cho thuê thiết bị mạng
PowerEdge T620 |
|
Form factor |
Tower (5U rack) |
Processors |
Intel Xeon processor E5-2600 product family |
Processor sockets |
2 |
Front side bus (FSB) |
2 x Intel QuickPath Interconnect (QPI) links: 6.4 GT/s, 7.2 GT/s, 8.0 GT/s |
Cache |
2.5MB per core; core options: 2, 4, 6, 8 |
Chipset |
Intel C600 |
Memory1 |
Up to 768GB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s |
PCIe slots |
7 PCIe slots: Four x16 slots with x16 bandwidth, full-length, full-height Two x8 slots with x8 bandwidth, full -length, full-height
One x8 slot with x4 bandwidth, full -length, full-height |
RAID controller |
Internal controllers: External HBAs (RAID): PERC S110 (software RAID; R720 only) PERC H810 PERC H310 PERC H710 External HBAs (non-RAID): PERC H710P 6Gbps SAS HBA |
Hard drives (hot-plug) |
Drive bay options: Up to 8 x 3.5” + 4 x Express Flash Up to 12 x 3.5” Up to 16 x 2.5” + 4 x Express Flash Up to 32 x 2.5” Hard drive options: 2.5” Express Flash , SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) 3.5” nearline SAS (7.2K), SATA (7.2K), SAS (15K)
Up to 48TB |
Feature |
Specification |
Integrated NIC |
Intel Dual Port 1GbE LOM |
Power supply |
Auto -ranging, Platinum efficiency 495W, 750W, or 1100W AC Gold efficiency 1100W DC |
Availability |
High-efficiency, hot-plug, redundant power supplies; hot-plug drive bays; TPM; dual internal SD support; hot-plug redundant fan; optional bezel; luggage-tag; ECC memory; interactive LCD screen; extended thermal support; ENERGY STAR compliant; switch independent partitioning |
Remote management |
iDRAC7 with Lifecycle Controller iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option) 8GB vFlash media (upgrade option), 16GB vFlash media (upgrade option) |
Systems management |
Dell OpenManage™ Essentials and Dell Management Console Dell OpenManage Power Center OpenManage Connections: OpenManage Integration Suite for Microsoft System Center Dell Management Plug-in for VMwarevCenter™ OpenManage Connections for HP Operations Manager, IBM Tivoli Netcool , and CA Network and Systems Management
IPMI 2.0 compliant |
Rack support |
ReadyRails™ sliding rails with optional cable management arm for 4-post racks |
Operating systems |
Microsoft Windows Server® 2008 R2 SP1, x64 (includes Hyper-V™ v2) Microsoft Windows HPC Server 2008 Microsoft Windows Small Business Server 2011 SUSE Linux Enterprise Server Red Hat Enterprise Linux Optional embedded hypervisors: Citrix XenServer™ VMware vSphere™ For more information on the specific versions and additions, visit
Dell.com/OSsupport. |
- CPU: 1xEight Core E5-2690 2.9Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xEight Core E5-2670 2.6Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xEight Core E5-2660 2.2Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xEight Core E5-2689 2.6Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xEight Core E5-2650 2.0Ghz 20MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xSix Core E5-2640 2.5Ghz 15MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xSix Core E5-2630 2.3Ghz 15MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
- CPU: 1xSix Core E5-2620 2.0Ghz 15MB Cache
- RAM: 4GB DDR3 PC3-1333/1600 ECC
- HDD: 2x Dell 250GB Enterprise SATA 3.5'' 7.2K
- DVD: CD/DVDROM
- RAID: PERC S110 Support Raid (0,1,5,10)
- NIC: Broadcom Dual-port Gigabit Ethernet
- Power Supply: 1x495Watts Hot-plug
Hàng nhập khẩu trực tiếp từ Mỹ.
